Troubleshooting Fax Troubleshooting 199
Confidential
050 TONE DETECT LEVEL 28~43 28 -dBm
Share with dial tone / busy tone.
051 TONE DET FRQ MIN 24~38 30 x10Hz
052 TONE DET FRQ MAX 47~67 50 x10Hz
053 TONE DET FRQ MIN (PBX) 245~350 245 Hz
054 TONE DET FRQ MAX (PBX) 470~670 670 Hz
055 ---
056 ---
057 ---
058 ---
059 AUTO LINE CHECK
On
Off
On
If there is no problem with telephone line or telephone line connection, set to
off when [automatic line check function] false detection [line unconnected] or
'line reverse insertion' error occurs.
060 DIAL TONE DETECT
On
Off
On
061 DT DET TIME 5~25 10 x100ms
In the initial setting, if the dial tone is detected for 1000 ms, it is judged that
there is a dial tone.
*The dial tone detection waiting time is fixed at 10s.
062 DT OFF IGNR TIME 5~28 28 x100ms
The dial tone off time of this set value is regarded as a dial tone continuation.
‘Connection line = PSTN
063 DT OFF IGNR TIME (PBX) 50~280 280 ms
The dial tone off time of this set value is regarded as continuation of dial tone.
‘Connection line = PBX
064 DT OFF PRE-PAUSE TIME 20~2550 30 x100ms
When dial tone detection = OFF, pause of this setting value is entered before
dialing.
065 ---
066 ---
067 ---
068 ---
Table 4-6. FAX Service Parameter Table
No. Parameter Name Setting Range Initial value Unit Remark

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
