EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Fax Troubleshooting 202
Confidential
091 RX PAPER WIDTH
A4
A4/B4
A4/B4/A3
Auto
Regardless of the paper size set in the apparatus,
It is used when you want to specify the paper width to receive fax fixed.
When changed, the receiving sheet width capability bit of the DIS signal to be
sent at the time of incoming call changes.
 Example of use
 When sending an A3 / B4 document on the sender side, judge whether
to transmit with A3 / B4 width or reduced size by looking at the
receiving paper width capability bit of the DIS signal of the receiver.
When the receiving sheet width capability bit = A 4, the image is
reduced / cut to A 4 and transmitted.
 A3 / B4 paper is not set on the device, but fax reception is done with A3
/ B4 and received as electronic data of A3 / B4 size by external memory
save / transfer
(Used when split printing is performed in full scale with substitution
output)
092 RX MAX LENGTH 1~65536 650
When the received original length exceeds this set value, the reception is
forcibly terminated.
093 ---
094 ---
095 ---
096 ---
097 ---
098 ---
099 ---
Table 4-6. FAX Service Parameter Table
No. Parameter Name Setting Range Initial value Unit Remark

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
