Troubleshooting Fax Troubleshooting 203
Confidential
100 REDUCT/CUTOUT SEND
Reduction Send
CutOut Send LEFT
CutOut Send CENTER
CutOut Send Right
Reduction Send
Process setting when the transmission document width differs from the
recording width of the receiver at the time of transmission
 Reduction Send = Reduction and sending
 CutOut Send LEFT = Cut the Left end, and sending on original size.
 CutOut Send CENTER = Cut the both end, and sending on original size.
 CutOut Send Right = Cut the Right end, and sending on original size.
101 V.29 EP TONE
On
Off
Off
When sending V.29 9600 / 7200 bps, add an echo suppressor tone.
It is used when a communication error has occurred due to the influence of
line echo of overseas communication.
102 1ST DIS IGNORE
On
Off
Off
Ignore the first DIS at the time of transmission and receive from the second
DIS.
103 RTC (EOL x12)
On
Off
Off
Select RTC signal [EOL × 6 / EOL × 12] at the end of the PIX signal
(switch from high speed to low speed)
104 ---
105 ---
106 ---
107 ---
108 ---
109 ---
110 COMM MONITOR
Until Detect
Always
Until Detect
 Until Detect
The monitor turns on when sending out and turns off when it detects a
facsimile signal.
 Always
The monitor is always on.
Since it is possible to listen to the signal at fax communication from the
monitor speaker, it is used at the time of investigation of image defect
trouble.
After troubleshooting confirmation, remember to return to original.
Table 4-6. FAX Service Parameter Table
No. Parameter Name Setting Range Initial value Unit Remark

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
