EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 223
Confidential
Figure 6-4. Ink Supply Mechanism (1)
No. Part/Component No. Part/Component No. Part/Component No. Part/Component
1 Foot (p. 277) 4
Ink Pack Tray BK/ Ink Pack Tray CL
(p. 263)
7 --- 10 ---
2
Temperature and Humidity Sensor (p.
263)
5 RIPS Front Cover (p. 263) 8 --- 11 ---
3 RIPS Unit (p. 263) 6 --- 9 --- 12 ---
2
5
1
1
3
4
