EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 234
Confidential
Figure 6-15. Optional Paper Cassette Unit (2)
No. Part/Component No. Part/Component No. Part/Component No. Part/Component
1 Paper Cassette 2nd Assy (p. 546) 4 Retard Roller (p. 546) 7 --- 10 ---
2 Lift Up Gear 30T (p. 546) 5
Extension Spring (Retard Roller) (p.
546)
8 --- 11 ---
3 Lift Up Sector Gear 40T (p. 546) 6 --- 9 --- 12 ---
4
1
3
5
2
