EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 266
Confidential
Ink Discharge
1. Connect the PC and printer with USB cable.
2. Start the adjustment program.
3. Select the Ink Eject from items on the adjustment program.
4. Execute the Ink Eject at following instruction on the adjustment program.
5. After finishing the Ink Discharge, Disconnect the AC cable from the printer to turn the printer off.
 Do not turn OFF the power by pressing the power button as that may cause ink to be re-
charged.
 Since the amount of consumption of ink is not counted, take note of the amount of ink
remaining in the Maintenance Box during Ink Discharge.
Ink Pack Tray BK/
Ink Pack Tray CL
1. Move the Lock Lever in the direction of the arrow, then open the RIPS Front Cover.
2. Push the Ink Pack Tray BK and Ink Pack Tray CL, then remove them.
A1
Lock
Lever
RIPS Front Cover
Ink Pack
Tray BK
Ink Pack
Tray CL
