3. RS232 (PC) port
4. RJ45 Ethernet port
5. USB port
Accessories
Transport wedges to be kept
Use accessories
• Tripod
&
• Recut lens tripod
&
• Stylus
• White felt tip marker
• Staedler permanent felt-tip pen
• Bag of 22 mm posiblocks
• Bag of 18x14 mm posiblocks
• Roll of 22 mm pads
• Roll of 18x14 mm pads
Tracing table accessories
• Pattern holder
• Pattern holder tip and holding screw
• Set of 2 small B-dimension wedges
Options
• Barcode reader
• Roll of barcode labels
• Table calibration pack
Connection accessories
• 220 V power cable
• RJ45 cable for the tracer-edger connection
2. CONNECTION TO AN EDGER
To connect the tracer-centerer-blocker to an edger, use the RJ45 cable (Neksia/Mr Orange edgers) or RS232
cable (Jess/Jessie /JessD/Kappa edgers) provided with the edger.
For the RS232 cable, refer to the labels indicating the direction of connection.
SIDE TRACER SIDE EDGER
