• After a job call the edging preparation screen appears automatically, followed by the centering screen.
• You can access the edging preparation screen at any time:
> select then .
To activate this working mode, select the following parameters in the configuration screen: (F p.97)
c. Displaying the binocular view
Once the tracing is finished, you can display a binocular representation of the job on a 1:1 scale, in order to
check the frame shape and centering.
Three values are displayed above the image:
• the frame base
&
• the curve angle
&
• the frame thickness
The indicator symbolizes the wearer side view.
In tracing - centering mode, the centering screen is displayed at the end of the tracing:
Select then to access the tracing screen.
The monocular view is displayed by default.
Press to display the binocular view.
