• input: 1.3 A
• output: 12 V - 3.3 A
Power supply voltage produced: 12 V continuous - 3.3 A
Power consumption: 40 W
Due to constant improvements, these specifications may be modified without prior notice.
2. ENVIRONMENT
Your machine should preferably be installed on a perfectly flat and stable work surface of suitable height (about 70 cm), free from shocks
and vibrations, to benefit from the high accuracy of your tracer-centerer-blocker. Your tracer may be installed on the right or left of your
edger. The tracer may be installed up to 5 m away from the edger (a 5 m cable is supplied with the edger). Longer cables are also available
on an optional basis.
The temperature and humidity of the room where you use your machine must be within the following ranges:
Operation:
• temperature between +10 °C and +40 °C
• Humidity: between 30% and 75%
Storage:
• temperature between -5 °C and 50 °C
• Humidity: between 25% and 95%
Altitude: < 2,000 m
Level of pollution: 2
Avoid sudden changes in temperature and humidity and install your system:
• in an area not directly exposed to sunlight
• away from all heat sources
• away from all strong magnetic fields
• away from all chemical products, corrosive vapours and liquids
Take care not to block the vents and to leave enough space above the device. Do not place any object on the device. Avoid exposing the
device to vibrations or shocks.
The back of your machine must be at least 20 cm away from a wall.
This machine is neither adapted nor intended to operate in an environment where there is a risk of explosion.
