For more information, refer to the section Preparing a drilled job (F p.73).
Press to go to the centering screen.
Tracing - tracing mode
In tracing - tracing mode, the result of the tracing is displayed in the work area of the tracing screen.
For more information on working modes, consult the section Perform a trace > Tracing environment >
Jobs and working modes (F p.18).
Before Centering
Once tracing has been carried out, you can:
• enter the curve angle and the frame base, for optimal centering precision
• add drilling to the shape. For more information, refer to the section Preparing a drilled job (F p.73).
b. Mechanical tracing
Detailed view of the pattern holder
1. Front tab
