Press to delete the ID.
Press on to confirm.
The letter A is displayed in the information bar.
The tracer is ready for tracing.
For further information, refer to the section concerning your type of job.
3. TRACING A RIMMED FRAME
Prerequisite:
• For correct tracing of the shape, the frame to be traced must not be deformed and its hinges must be
closed.
• For a small frame, place the two wedges between the tracing table clamps:
This section describes the procedure to follow for tracing rimmed frames including high-base frames:
• symmetric binocular
&
mechanical tracing of a rimmed frame
• asymmetric binocular
&
tracing of a rimmed frame
• monocular tracing of a rimmed frame
• monocular tracing to cut only one lens of a rimmed frame
Place the frame in the tracing table, between the two clamps located opposite you.
Gently close the jaw to hold the frame.
