Position the lens on the tripod.
In the case of focimeter dots: Slowly move the lens until the three focimeter dots are perfectly aligned
on the test card.
In the case of micro-engravings: Slowly move the lens until the micro-engravings are perfectly aligned
on the test card.
Yellow indicators are displayed when the focimeter dots or micro-engravings are detected.
For the three focimeter dots:
• place the central point in the square ,
• place the two external points between the two dotted lines, as close as possible to the central line.
The indicators are displayed in green.
The lens is centered and ready to be blocked.
Three focimeter dots Micro-engravings
To carry out lens blocking, refer to the section Lens Centrering > Blocking a lens (F p.61).
