Basic Navigation 17
Set Temp Alarm [Power]
The Temp Alarm is used to generate a warning when the ambient temperature monitored by the rack
exceeds a user-defined level. Use the Set Temp Alarm menu to set that level for the selected rack.
Configure Fan [Power]
The Configure Fan menu allows you to configure the behavior of the fan in the selected rack. Available
settings include: No Data/15 Min and Always On. No Data/15 Min will allow the fan to shut off if there
have been no dimmer levels sent to that rack in 15 minutes. When levels are sent to dimmers in the
rack, the fan will start up automatically. The fan will always run for 15 minutes following a reset of the
CEM+.
Air Filter Timer [Power]
The Air Filter Timer menu allows you to set the amount of time between air filter cleaning reminders for
a selected rack. This timer counts down only when the fan is running in the rack.
Voltage Headroom [Power]
This menu allows you to specify the threshold for the incoming voltage at which a warning will appear
to notify you about a drop in voltage.
Set Network [Power]
Set Network allows a User to enable or disable the network, enable or disable BootP (defaults to
disabled) and set the network addressing for a selected rack.
Network Defaults [Power]
Choosing yes from this menu will reset your network table (IP addresses, subnet masks, and gateway
IPs) to their defaults for the current Group and Rack settings.
Get Config [Power]
After selecting this function, you will be prompted with the name of the rack you want to get the
configuration from.
Options will include:
• Racks [1-16] which refers to any of the other racks that may be online and configured as being
from the same group.
• FTP Server which refers to an FTP server if one is configured on your lighting network. It will ask
you to specify the server’s IP address. See the section
FTP Server
on
page 51
for more information
about setting up an FTP server for use with CEM+.
• Stored in Rack which refers to the configuration information stored in the back plane of the local
rack.
Once the configuration source has been chosen, it will transfer the configuration to the local CEM+.
After the transfer is complete, you will get a confirmation or error message for the transfer.
Send Config to All [Power]
Upon pressing for this function, you will immediately send the locally contained configuration out
to all of the other CEM+ modules in the group and to the FTP server if one is configured for the group.
See the section
FTP Server
on
page 51
for more information about setting up an FTP server for use with
CEM+.
Delete All Racks [Power]
Choosing yes from this menu clears the rack configuration from the local rack (the one you are logged
into), but does not clear everything from the CEM+. The network settings, and custom PIN for the face
panel remain intact.
