7800 MultiFrame Manual
7812DCDA2Q-HD (-AA, –AES4) Dual Path HDTV Down-converter
Page 24 Revision 1.0
Figure 7-6: H Phase Offset Slider
7.1.5. Loss of Video Mode
This control defines the action that will be taken when the input video is lost. You can choose to freeze the
output video on the last good frame of input video, force the output video to black or force the output video
to blue. The VLPRO interface for changing the Loss of Video Mode control appears as shown in Figure
7-7.
Figure 7-7: Loss of Video Mode Drop Down Menu
Black
Upon loss of video, the module’s output will be forced to black.
Blue
Upon loss of video, the module’s output will be forced to blue.
Freeze
Upon loss of video, the module’s output will be forced to be the last good frame of
input video
