7800 MultiFrame Manual
7812DCDA2Q-HD (-AA, –AES4) Dual Path HDTV Down-converter
Page 78 Revision 1.0
9.2. VISTALINK
®
MONITORED PARAMETERS
The following parameters can be remotely monitored through the VistaLINK
®
interface.
Parameter Description
Input Video Standard
Displays the current Input Video Standard.
Video Delay
Reports video delay through the card in ms.
CDP Parser
Displays the status of Closed Caption reading process and indicates if
any syntax errors are encountered within inbound CDP packets.
Video Payload ID
Reports if a valid Video Payload ID ANC packet has been detected and
indicates the format in which the video is being sent to the card.
Input AFD Code Status
Reports any detected AFD values on the incoming video signal.
Output AFD Code Status
Presents the AFD code being stamped on the output of the card (if
applicable).
SRC Status
Displays the status of the Sample Rate Converters.
Audio Delay
Displays the delay of the audio in ms.
Video Delay
Displays the delay of the associated video in ms.
Table 9-1: VistaLINK
®
Monitored Parameters
