7800 MultiFrame Manual
7812DCDA2Q-HD (-AA, –AES4) Dual Path HDTV Down-converter
Page 82 Revision 1.0
Composite Display
Defines if the composite analog video signal will be generated to
support only Black and White displays or if it will be configured to
support color displays.
Output Level
Set the gain levels for the composite analog video output.
Composite Hue
Sets the hue for the composite analog video output.
Brightness
Sets the Brightness for the composite analog video outputs.
NTSC Pedestal Setup
Controls whether setup is inserted into the outgoing composite
analog video signal.
Line 21 Setup Pedestal
Controls whether setup is inserted into line 21 of the outgoing
composite analog video signal.
PGM 1A/2A
Configured together to output either SDI or composite analog video.
PGM 3A/4A
Configured together to output either SDI or composite analog video.
Analog Audio DAC Gain
Defines if the output analog audio levels will be 18 dbU or 24 dbU.
Analog Audio Output Source
Defines the desired Output Channel Mixer as the source of audio for
Analog Audio.
AES Output Source 1A
Defines the desired Output Channel Mixer as the source of audio for
AES1A.
AES Output Source 1B
Defines the desired Output Channel Mixer as the source of audio for
AES2A.
AES Output Source 2A
Defines the desired Output Channel Mixer as the source of audio for
AES3A.
AES Output Source 2B
Defines the desired Output Channel Mixer as the source of audio for
AES4A.
Table 9-2: VistaLINK
®
Controlled Parameters
