7800 MultiFrame Manual
7812DCDA2Q-HD (-AA, –AES4) Dual Path HDTV Down-converter
Revision 1.0 Page 83
9.4. VISTALINK
®
TRAPS
Parameter Description
SD CC1 to SD CC3 Not Present
Displays the trap status of Standard Definition Closed Captioning
for captions 1 to 3.
CEA708 Service 1 to CEA708
Service 16 Not Present
Displays the trap status of CEA708 Service 1 to 16.
CDP Parser
Displays the status of Closed Caption reading process and
indicates if any syntax errors are encountered within inbound CDP
packets.
Video Missing
Displays the status of the video missing trap.
Audio Group 1 to 4 Not
Present
Displays the trap status of audio group 1 to 4.
AFD Loss
Displays the status of the AFD loss trap.
AES1 to AES8 Loss
Displays the trap status of AES1 to AES8.
Temperature
Displays the status of the temperature trap.
Table 9-3: VistaLINK
®
Trap Parameters
