7800 MultiFrame Manual
7812DCDA2Q-HD (-AA, –AES4) Dual Path HDTV Down-converter
Page 28 Revision 1.0
Figure 7-12: Audio Tab
"
Any changes to the audio settings will cause a momentary interruption on the output
audio.
7.2.1. Selecting The Audio Delay
This control adjusts the audio delay +/- 350 ms. This delay is relative to the delay that the module
automatically inserts to match audio path and video path delays. The VLPRO interface for the Audio
Delay control is shown in Figure 7-13.
"
Note: Negative values are limited to the amount that cause the delay to be only the
audio processing delay, the card does not have negative delay ability.
Figure 7-13: Audio Delay Control
