7.4.6. Setting the Gamma Level
With this control the user can adjust the overall Gamma correction factor from - 128 to + 127 in increments
of 1. Move the relevant slider bar to the left or right to select the desired gamma correction factor.
Gamma Level Ranges from –128 to 127 in 1 level increments.
7.4.7. Setting the Red, Green, Blue Gamma Levels
With these controls, the user can adjust the gamma individually for Red, Green, and Blue Gamma
components – 128 to + 127 in increments of 1. Move the relevant slider bar to the left or right to select the
desired gamma correction factor.
Red Gamma Level Ranges from –128 to 127 in 1 level increments.
Green Gamma Level Ranges from –128 to 127 in 1 level increments.
Blue Gamma Level Ranges from –128 to 127 in 1 level increments.
7.4.8. Reset Button
By pressing the Reset button, all Video Processing parameters in this control tab will return to their default
settings.
