7800 MultiFrame Manual
7812DCDA2Q-HD (-AA, –AES4) Dual Path HDTV Down-converter
Revision 1.0 Page 81
First Pixel Num In SD Clean
Ap
Defines the first active line for the SD Production Aperture.
Last Pixel Num In SD Clean
Ap
Defines the last active line for the SD Production Aperture.
First Line Num In SD Prod Ap
Defines the first active horizontal pixel for the SD Clean Aperture.
Last Line Num In SD Prod Ap
Defines the last active horizontal pixel for the SD Clean Aperture.
First Line Num In SD Clean
Ap
Defines the first active line for the SD Clean Aperture.
Last Line Num In SD Clean Ap
Defines the last active line for the SD Clean Aperture.
AFD Input Enable
Enables the input side AFD processing.
Loss of AFD Mode
Configures the action that the converter will take when incoming AFD
signals are lost.
AFD Stamp Source
Selects the AFD signal that will be stamped on the output signal.
Output SD Aspect Ratio
Defines whether SD outputs should be stamped with an AFD value
that indicates a 16:9 or 4:3 output image raster.
AFD Output Enable
Enables the insertion of AFD packets in the outgoing video signal.
AFD Output Line
Sets the AFD Output Line level.
L Source
Assign a channel to L Source.
R Source
Assign a channel to R Source.
C Source
Assign a channel to C Source.
LFE Source
Assign a channel to LFE Source.
Ls Source
Assign a channel to Ls Source.
Rs Source
Assign a channel to Rs Source.
Output Scaling Mode
Controls whether the down mix matrixing is normalized or not.
Output Gain
Configures the output gain.
LFE Mixing
Controls whether the LFE channel is included or not in the audio
down-mixing.
LFE Gain
Controls the LFE channel gain after audio is up-mixed.
Surround Phase
Controls whether a 90 degree phase shift is applied to the surround
channels before being passed to the down-mix matrix.
Down Mix Type
Sets the type of audio down-mixing that will be performed.
LR_lev
Sets the LR_lev level.
C_lev
Sets the C_lev level.
Ls_lev_L
Sets the Ls_lev_L level.
Rs_lev_L
Sets the Rs_lev_L level.
Ls_lev_R
Sets the Ls_lev_R level.
Rs_lev_R
Sets the Rs_lev_R level.
