7800 MultiFrame Manual
7812DCDA2Q-HD (-AA, –AES4) Dual Path HDTV Down-converter
Page 80 Revision 1.0
G Gain
Adjusts the Gain value of the G component in the RGB Domain.
G Offset
Sets the Offset in the RGB Domain.
B Gain
Adjusts the Gain value of the B component in the RGB Domain.
B Offset
Sets the Offset in the RGB Domain.
Saturation Gain
Sets the saturation gain level.
Video Gain
Sets the video gain level.
Gamma Adjust
Enables gamma adjust. When enabled, the module will allow the
user to adjust the gamma level
Gamma Level
Sets the gamma correction level.
Red Gamma Level
Adjusts the Red Gamma levels.
Green Gamma Level
Adjusts the Green Gamma levels.
Blue Gamma Level
Adjusts the Blue Gamma levels.
H Filter Cutoff
Sets the type of the horizontal filter in the scaler.
V Filter Cutoff
Sets the type of the vertical filter in the scaler.
Red Panel
Sets the value for the R component of the background side panels.
Green Panel
Sets the value for the G component of the background side panels.
Blue Panel
Sets the value for the B component of the background side panels.
AFD Stamp
Selects the AFD signal that will be stamped on the output signal.
Aspect Ratio Conversion
Selects the aspect ratio conversion that the module will perform.
Input H Start
Sets the left side crop position.
Input H Stop
Sets the right side crop position.
Input V Start
Sets the top crop position.
Input V Stop
Sets the bottom crop position.
CC Enable
Enables closed caption handling.
Loss of CC Timeout
When video is lost, this control sets the amount of time (in seconds)
before the Closed Captioning timeouts.
Recall Preset
Used to recall a current card configuration from one of the user
presets.
Store User Preset
Used to store the current card configuration.
Auto Recall Preset
Enables automatic preset recall when input or output changes.
Ap Aspect Ratio Source
Selects whether the Production Aperture or the Clean Aperture is
used when converting input signals.
First Pixel Num In SD Prod Ap
Defines the first active horizontal pixel for the SD Production
Aperture.
Last Pixel Num In SD Prod Ap
Defines the last active horizontal pixel for the SD Production
Aperture.
