7800 MultiFrame Manual
7812DCDA2Q-HD (-AA, –AES4) Dual Path HDTV Down-converter
Page 2 Revision 1.0
 5.1 PCM to Stereo (Lt/Rt or Lo/Ro) down-mixing
 4x analog audio outputs per processing channel with the –AA version of the 7812DCDA2Q-HD
 2x AES audio outputs per processing channel with the –AES4 version of the 7812DCDA2Q-HD
 Transports closed caption and time code information from input to output with all necessary HD to
SD translations and time code re-calculations taking place.
 VistaLINK
®
- capable offering remote control and configuration capabilities via SNMP using
VistaLINK
®
PRO or CP-2200E Network Control Panels. VistaLINK
®
is available when modules are
used with the 3RU 7800FR and a VistaLINK
®
Frame Controller
This manual will serve to cover the 7812DCDA2Q-HD, the 7812DCDA2Q-HD-AA and the 7812DCDA2Q-
HD-AES4 versions.
Module
HD Re-
clocked
Outputs
SD-SDI
Program
Outputs
NSTC/PAL
Program
Outputs
HD to SD
Processing
SD to SD
Processing
Audio
Outputs
7812DCDA2A-
HD
Supported Supported Supported Supported
Pass
Through
Embedded Only
7812DCDA2Q-
HD-AA
Supported Supported Supported Supported Pass
Through
Embedded and
4x Analog
Audio Per Path
7812DCDA2Q-
HD-AES4
Supported Supported Supported Supported Pass
Through
Embedded and
2x AES Per
Path
