Evoqua DEPOLOX - Page 161

DEPOLOX
®
Pool Sensor Measuring Modules and Spare Parts
WT.050.570.000.DE.IM.0714 161
Flow block assembly, pressurised part no. W3T158599 REF: WAE4161
Item Part no. Designation Item Part no. Designation
1 W3T164571 Basic housing, pre-assembled 32 W3T159707 Union end
2 W2T507548 Rating plate 33 W3T172975 O-ring
3 W3T160629 Housing cover 34 W3T168189 Fine filter
4 W3T172038 Product label 35 W3T158602 Filter unit
5 W2T506143 Cable clamp 36 W2T505463 Self-tapping screw
6 W3T172029 Multi-sensor 39 W3T172041 Securing ring
7 W3T166170 Stop valve 40 W3T158576 Drain tube
9 W2T507615 Flat nut 41 W3T172997 O-ring
10 W3T158559 Cell body 42 W3T164597 O-ring
11 W3T164226 Compression spring 43 W3T158575 Drain screw
12 W3T158569 Membrane unit 44 W3T166160 Gasket EPDM
13 W3T160654 O-ring 45 W3T172556 O-ring
14 W3T158595 Control valve body 46 W3T158563 Cell body cover
15 W2T504209 Plastic cartridge 47 W3T160657 O-ring
16 W3T160649 V profile clip 48 W3T161450 Plug
17 W3T158567 Square nut 49 W3T168859 O-ring
18 W2T504659 Screw 50 W3T172861 O-ring
19 W2T506019 Washer 51 W3T161501 Hose nipple
20 W3T158572 Valve needle 52 W3T169815 Clamping ring
21 W3T172795 Compression spring 53 W3T161502 Union nut
22 W3T158573 Adjustment screw 54 W3T158601 Hose
23 W3T160357 O-ring 55 W2T505093 Angle reducer
24 W3T160650 Flow distributor cap 78 W3T166169 Clip
25 W3T160655 O-ring 79 W3T172045 Electrode support
26 W3T160648 Check valve housing 80 W3T161561 Screw cap
28 W3T161396 O-ring 81 W3T168162 Protection plug
29 W3T169827 Cone 82 W3T164588 Protection plug
30 W3T172946 Ball 83 W3T161453 Protection plug
31 W3T172949 O-ring 98 W3T158600 Beaker
Pre-assembled assemblies
W3T166172 Cell body, complete assembly Comprising: Items 10-25, 46-49, 55, 83
W3T158603 Non-return valve Comprising: Items 26, 28-33, 50, 80
W3T166171 Drain unit Comprising: Items 39-45, 81
W3T166194 Fine filter Comprising: Items 33-34
W3T163739 Seat Comprising: Items 31-33
Spare part set
W3T158874 Maintenance part set, annual
maintance
Comprising: Items 1, 32, 44, 45, 95, 98, 100
special grease UNISILKON (tube, W2T504248)
W3T158878 Maintencance part set, every 4
years
Comprising: Items 1, 7, 25, 28, 32, 41, 42, 44, 45, 47, 49, 50,
95, 98, 100
special grease UNISILKON (tube, W2T504248)
W3T158882 Set of spare parts for volumetric
flow control
Comprising: Items 1, 11–23, 36, 100
special grease UNISILKON (tube, W2T504248)
W3T166180 Set of seals für Leitfähigkeitssensor
