The following are integrated into the cover (1, Bild 4):
 The graphic display (5)
 The operating elements (4)
 A green LED (2) for indication of the power supply
 Eight red LEDs (3) for indication of operating conditions
Fig. 4 Electronic module
1
2
3
5
4
