City Classic CR
Memokey
Ref.3620 + Ref.3621
Keypad
• Access control keypad which allows the door to be opened
when a pre-programmed code of up to 6 digits is entered.
• Capacity for up to 100 user codes.
• Length 4 to 6 digits.
• Confirmation tone sounds when a button is pressed and to
indicate if the code entered has been accepted/rejected.
• Reader (ref.3620) and controller (ref.3621) in two
independent modules.
• The controller is installed in the building's interior near the
power supply and lock-release.
• The metallic box is included with the controller.
• Flush mounted (ref.8948, including box) or surface
installation (ref.8951, optional).
• A second keypad CR can be added in the building's
interior.
• Maximum distance between reader and controller of 100m.
• Reader and controller not integrated within the same
module.
TECHNICAL FEATURES
INSTALLATION
PROGRAMMING
• 2A relay lock-release activation (NA, NC).
Programmable at from 1 and 99 seconds or bistable.
• Exit button input.
• Free access button input (trades).
• Auxiliary Open Collector Output (150mA max) to
indicate a vandalism attempt or open/forced door.
• Each code can activate 2 relays at the same time.
The CR keypad is located in the exterior of the building and
is connected to the controller in the interior in the same way
as the rest of the device (power supply and lock-release).
An exit button can be used optionally.
Programming from the same keypad using
a master code.
SPECIFICATIONS
Dimensions: (horizontal)x(vertical)x(depth) mm
• Dimensions:
* Reader
* Flush Mounted Box
* Surface Box
* Metallic Box
• Environmental Protection (IP)
* Anti-Shock Protection (IK)
• Power Supply (V)
• Consumption (mA) s/lock-release
• Operating Temperature
130x128
115x114x45
130x128x33
154x203x50
43
07
12V (ac/dc)
6/60
0º to 70º C
Lock-Releases
Exit Button
Power Supply
Ref.3621
Ref.3620
230Vac
2
2
6
STAND-ALONE
12Vdc
12Vac
30708
3071
2888
2880
* Door lock recommended.
Normal
References
Reinforced
