IDENTIFIERS
1. Card without magnetic strip (ref.23361); 2. Card with magnetic strip
(ref.2336); 3. Proximity keyring (ref.44501).
1 2
3
CENTRALISED
Proximity+Display
CAC Attendance
reader
Ref.6955
TECHNICAL FEATURES
• Recommended for work schedule and access control
monitoring in businesses, industries or offices.
Includes proximity reader and display for viewing
messages and clock-in date/times.
Reader that lets you open the door with an approaching
proximity card or keyring. Only authorized cards will
trigger the device. No physical contact is necessary. The
display shows the message.
• Integrated in aluminium panel.
• Flush-fit embedded (ref. 8854, including box) or surface
mounted (ref. 7064, optional).
• Recommended for indoors and outdoors.
• Reader and controller integrated in the same module.
Configuration as a CENTRALISED CAC:
• Capacity:
- 2.048 user cards/key rings with CAC central unit (ref. 4410).
• Display message confirmation of acceptance or rejection
of card presented.
PROGRAMMING
Programming is done using the relevant PC software
to the central unit installed (ref.4410).
• No physical reader-card contact required. Reading
distance 5 cm (card) or 1.5 cm (key ring).
• Display shows visual information on actions.
• Reader wiring:
- From display module to Central Unit: 2 wires (power
supply) + shielded twisted pair (data). In an installation
with several readers they may be connected in cascade.
Dimensiones: (horizontal)x(vertical)x(profundidad)mm
SPECIFICATIONS
• Dimensions:
* Reader
* Flush Mounted Box (included)
* Surface Box (optional)
• Environmental Protection (IP)
• Anti-Shock Protection (IK)
• Power Supply (V)
• Consumption (mA) S/lock-release
• Operating Temperature
130x199
115x185x45
130x199x33
54
07
12Vdc
90
-10º a 55ºC
INSTALLATION
Reader
Reader
Reader Reader
Up to 32 readers
2 2
2
2
2
C.U. (ref.4410)
Twisted Pair
Power Supply
To Next Page
