Mono-Channel
Receiver
Ref.7900
Radio Frequency
• 433.92 MHz monochannel receiver.
• Trinary technology.
• The receiver accepts all emitters (ref.79561) which are
coded with the same code.
• These can be installed in the FERMAX door entry/video
door entry panels' flush mounted box.
• It could be installed 2 independent receivers with the same
two-channel transmitter (ref.79561).
COMPATIBLE WITH:
INSTALLATIONTECHNICAL FEATURES
• Conguration by means of trinary dipswitch.
(8 microswitches at 3 positions).
• Power supply: 12Vdc / 12Vac
• Frequency: 433.92 MHz.
• 12Vac Output to activate the lock-release.
• Output for button connection to open the door from
the interior.
• Dimensions: 20x70x60.
Trinary emitters (ref.79561).
Ref.7900
Installed inside
the flush-mounted box.
Exit Button
RF Emitter (ref.79561).
Power Supply
230Vac
Lock-Release
2
2
2
STAND-ALONE
12Vdc
12Vac
30708
3071
2888
2880
* Door lock recommended.
Normal
References
Reinforced
