STAND-ALONE
12Vdc
12Vac
30708
3071
2888
2880
* Door lock recommended.
Normal
References
Reinforced
COMPATIBLE WITH:
TECHNICAL FEATURES
• Includes a 25cm rigid antenna.
• Alternatively the user can use card ref.7934,
which converts the receiver into a dual-channel
device which activates a second relay.
• Receiving frequency: 433.92 MHz.
• Sensitivity: 3mV.
• Relay Contact: 2A max.
• Power supply: 220Vac / 50Hz.
• Consumption: 110mA on standby.
• Dimensions: 90x165x55.
Trinary emitters (ref.79561).
Garage Receiver
Ref.7952
Radio Frequency
• 433.92 MHz monochannel receiver.
• Trinary technology.
• The receiver accepts all emitters (ref.7956) with the
same code.
• When receiving the code, the receptor closes the
circuit which activates the lock-release or door
mechanism.
• Assembled in an ABS airtight box (IP65).
• Programmed via 8 micro-switches with 3 positions each.
INSTALLATION
RF Emitter
Ref.79561
Ref.7952
Ref.7934
Lock-Release
Alarm
2
2
