Loft Memokey
Ref.4540
Keypad
• Access control keypad which allows the door to be
opened when a pre-programmed code of up to 6
digits is entered.
• Membrane keypad finished in texturised ABS plastic
with status LEDs.
• Surface installation.
• Capacity: up to 100 user codes.
• Length 4 to 6 digits.
• Recommended for interior use.
• Includes 50cm of wiring.
• Reader and controller integrated within the same module.
• Acoustic confirmation tone which sounds when a
button is pressed. Acoustic and visual confirmation
with LED’s showing if a code has been accepted/
rejected.
TECHNICAL FEATURES INSTALLATION
PROGRAMMING
• 2A relay lock-release activation (NA, NC).
Programmable at from 1 and 99 seconds or
bistable.
• Exit button input.
• Free access button input (trades).
• Auxiliary Open Collector Output (max. 150 mA) to
indicate a vandalism attempt or open/forced door.
• Tamper proof to indicate vandalism attempts.
The keypad is located in the exterior area. The rest of
the devices are connected to this module and they are
installed in the building's interior: power supply and lock-
release. An exit button can be used optionally.
Programming from the same keypad using
a master code.
SPECIFICATIONS
Dimensions: (horizontal)x(vertical)x(depth) mm
• Dimensions:
* Reader
* Flush Mounted Box
* Surface Box
• Environmental Protection (IP)
• Anti-Shock Protection (IK)
• Power Supply (V)
• Consumption (mA) s/lock-release.
• Operating Temperature
60x130x23
Not required
Not required
66
06
12V (ac/dc)
20/70
0º to 70º C
Lock-Releases
Exit Button
Power Supply
Ref.4540
230Vac
2
2
2
2
Marine Memokey
STAND-ALONE
12Vdc
12Vac
30708
3071
2888
2880
* Door lock recommended.
Normal
References
Reinforced
