Digital RF Emitter
Ref.24651
Radio Frequency
• 433.92 MHz radio frequency emitter.
• Digital technology.
• Innovative and very robust design.
• Dual channel which can activate two relays.
• Secure, unique code, which is non-configurable and
corresponds to the emitter series.
• The emitters must be activated/deactivated on the
receivers.
COMPATIBLE WITH:
TECHNICAL FEATURES
• Code which is unique and exclusive to the emitter.
• Includes a 12Vdc battery.
• Distance: 30m.
• Frequency: 433.92 MHz.
• Consumption when transmitting: 10mA.
• Standby Consumption: 0.1mA.
• Dimensions: 53x63x13.
Stand-alone Chalet receptor (ref.7960).
INSTALLATION
Lock-Release
Power Supply
230Vac
RF Receiver ref.7960RF Emitter ref.24651
2
2
STAND-ALONE
12Vdc
12Vac
30708
3071
2888
2880
* Door lock recommended.
Normal
References
Reinforced

Fermax Cityline Specifications

General

Weather Resistance	Yes
Operating Voltage	12 Vdc
Microphone Sensitivity	-40dB
Housing Material	Aluminum
Type	Video Intercom
Installation	Wall-mounted
Frequency Response	300Hz - 3.4kHz
Weight	Varies depending on module configuration
