Marine Memokey
Ref.4699
Keypad
• Access control keypad which allows the door to be
opened when a pre-programmed code of up to 6
digits is entered.
• Capacity: up to 100 user codes.
• Length 4 to 6 digits.
• Integrated within a 2.5mm stainless steel Marine panel.
• Flush mounted (ref.4641, including
box) or surface installation (ref.4701, optional).
• Recommended for interior and exterior use.
• Reader and controller integrated within the same module.
• Acoustic confirmation tone which sounds when a
button is pressed. Acoustic and visual confirmation
with LED’s showing if a code has been accepted/
rejected.
• Blue backlit zamak keypad with status LEDs.
TECHNICAL FEATURES INSTALLATION
PROGRAMMING
• 2A relay lock-release activation (NA, NC).
Programmable at from 1 and 99 seconds or bistable.
• Exit button input.
• Free access button input (trades).
• Auxiliary Open Collector Output (max. 150mA) to
indicate a vandalism attempt or open/forced door.
• Each code can activate 2 relays at the same time.
The keypad is located in the exterior area. The rest of the
devices are connected to this module and installed in the
building's interior: power supply and lock-release. An exit
button can be used optionally.
Programming from the same keypad using
a master code.
SPECIFICATIONS
Dimensions: (horizontal)x(vertical)x(depth) mm
• Dimensions:
* Reader
* Flush Mounted Box
* Surface Box
• Environmental Protection (IP)
• Anti-Shock Protection (IK)
• Power Supply (V)
• Consumption (mA) S/lock-release.
• Operating Temperature
150x180
130x160x55
154x184x55
54
09
12V (ac/dc)
40/110
-15º to 55º C
Lock-Releases
Exit Button
Power Supply
Ref.4699
230Vac
2
2
2
2
STAND-ALONE
12Vdc
12Vac
30708
3071
2888
2880
* Door lock recommended.
Normal
References
Reinforced
