CENTRALISED
Programming is done using the relevant PC software
to the central unit installed (ref.2405 or ref.4410).
PROGRAMMING
• Independent Operation:
- Proximity: swipe the proximity card or proximity
keyring.
- Keypad: user code (up to 6 digits): «CODE+B»
• System operation for greater security:
- Card+PIN code: swipe the proximity card or keyring +
4 digit PIN code: «CARD+CODE (4 digits)+B».
• Does not require physical reader-card contact. 2cm
(card) or 0.5cm (keyring) reading distance.
• Acoustic and visual status data.
• The Wiegand Readers (WG-Data/Clock) allow greater
anti-sabotage security given that all the devices are
connected to the door controller and are therefore
outside the range for interference. The door controller
is installed in the interior area (secure area) and the
reader in the exterior.
• The reader can be used with other door controllers
which use Wiegand 26 (WG-Data/Clock) protocols.
• Wiring: 7 wires to the door controller.
• For more information see the door controller's
Technical Features section.
TECHNICAL FEATURES
SPECIFICATIONS
Proximity and Keypad
Wiegand26-Data/Clock
Loft Proximity+Keypad
Ref.4550
• Double technology access control reader: proximity and
keypad.
• Operates independently or as a system for greater security.
• Module nished in textured ABS plastic.
• Surface installation.
• Recommended for interior use.
• Includes 50cm of wiring.
• Requires a door controller (ref.4420) for its connection
and operation.
• Independent Operation:
- Proximity: allows the door be opened when a card or
proximity keyring is swiped.
- Keypad: allows the door to be opened when a
pre-programmed 4 to 6 digit code is entered.
• System operation for greater security: card+PIN code
(4 digits only).
• Proximity reader with capacity for up to (according to
operation selected):
- 1.020 cards/keyrings/codes/card+PIN code with
MDS central unit (ref.2405).
- 2.048 cards/keyrings/codes/card+PIN code with
CAC central unit (ref.4410).
• Acoustic and visual confirmation using status LEDs
which advises if the card swiped has been accepted or
rejected.
60x130x23
Not required
Not required
66
06
12Vdc
40
0º to 60ºC
• Dimensions:
* Reader
* Flush Mounted Box
* Surface Box
• Environmental Protection (IP)
• Anti-Shock Protection (IK)
• Power Supply (V)
• Consumption (mA) S/lock-release
• Operating Temperature
Dimensions: (horizontal)x(vertical)x(depth) mm
INSTALLATION
See “Installation
Diagram for readers
with door controller
(Wiegand 26-Data
Clock)”.
IDENTIFIERS
1. Card without magnetic strip (ref.23361); 2. Card with magnetic strip (ref.2336);
3. Proximity keyring (ref.44501).
1 2
3
