7 Speed mode and force/torque mode
184 Festo – GDCP-CMMS/D-FW-EN – 1404NH – English
7.1.3 Connection: Analogue and digital inputs/outputs
The connection diagram shows the required digital inputs for the speed mode.
24 V DC
Controller enable (DIN5)
Output stage enable (DIN4)
Limitswitch0(DIN6)
1)
Limitswitch1(DIN7)
1)
Common error (DOUT3)
2)
Screening (SG N D)
Controller ready for operation (DOUT 0)
Motion complete ( DOUT1)
2)
Star t confirmed (DOUT2)
2)
12
9
21
22
10
14
2
15
1
24
13
25
Setpoint
value:
-10…+10 V
Load “DIN/DOUT” (GND 24 V)
6
4
Analogue input, differential (#AIN0)
Analogue input, differential (#AIN0)
Referenc e voltage output (VREF
OUT
), +10 V DC
Analogue load ( AGN D), reference potential “reference
voltage output/analogue inputs”
CMMS/CMMD
X1/X1.1/X1.2
1) The limit switches are set by default to N/C contact (configuration over FCT)
2) Default setting, freely configurable in the Festo Configuration Tool (FCT).
Fig. 7.3 Connection: Analogue and digital inputs/outputs
