9.3.3 Configure/parameterise analogue monitor
The following parameters ( FCT) can be configured/parameterised for the analogue monitor:
Settings
Description
Analogue Output
Analogue Monitor The following signals c an be output as analogue monitor signal:
– Speed setpoint value
– Speed actual value (raw)
– Speed actual value (filtered)
– Position setpoint value
– Position actual value
– Effective current setpoint value
– Effective current actual value
– Reactive c urrent setpoint value
– Reactive c urrent actual value
– Phase current U
– Phase current V
– Rotor position
– Following error
– Output stage voltage
– Fixed voltage level
Scaling Value for scaling of the “analogue monitor” parameter to the analogue
output signal (0…10 V)  Fig. 9.7.
Offset Value for the height of the “Offset” voltage shift to the load
(AGND)[X1.14]  Fig. 9.7/Fig. 9.8.
Numeric Overflow
Limitation
Func tion for overflow limitation of the analogue output signal
 Fig. 9.8.
Tab. 9.2 Configure/parameterise analogue monitor
