2Interfaces
34 Festo – GDCP-CMMS/D-FW-EN – 1404NH – English
2.3.2 Power su pply, motor and motor encoder interfaces
X9
1 x 110 … 230 V AC
1
2
3
4
5
6
7
24 V DC
Power ON/OFF
X6.2
X2.2
9
GND
8
X6.1
X2.1
9
GND
8
Axis string 2
Axis string 1
Fig. 2.10 Overview: Power supply, motor a nd motor encoder interfaces
