A Diagnostic messages
232 Festo – GDCP-CMMS/D-FW-EN – 1404NH – English
A.4 Profibus diagnostics
Diagnostic messages
Unit_Diag_Bit No. Message Reaction
00 E429 “Position data set” 42-9 Error in position data set PS off
01 E703 “Opera ting mode” 70-3 Operating mode error configurable
02 E702 “Arithmetic error” 70-2 General arithmetic error PS off
03 E421 “Position
precomputat io n”
42-1 Positioning: Error in pre-co mputation configurable
04 E163 “Unexpected state” 16-3 Unexpected status / programming
error
PS off
05 E010 “Stack Overflow” 01-0 Stack overflow (internal error) PS off
06 E261 “Checksum error” 26-1 Checksum error PS off
07 E162 “Initialisation” 16-2 Initialization fault PS off
08 E290 “NoSDavailable” 29-0 No S D available configurable
09 E291 “SD initialisation” 29-1 SD initialization error configurable
10 E292 “SD parameter set” 29-2 SD parameter set error configurable
13 E222 “PROFIBUS
communication”
22-2 PROFIBUS co mmunicat ion error configurable
14 - “unknown” 12-0 CAN: General error configurable
12-1 CAN: Error bus off configurable
12-2 CAN: Error when transmitting configurable
12-3 CAN: Error receiving configurable
12-5 CAN: Error in the IPO mode configurable
15 E790 “RS232 c ommunication
error”
79-0 RS232 communication error configurable
16 E761 “S SIO co mmunica tion” 76-1 Error SSIO c ommunication (axis 2) configurable
17 E760 “S SIO co mmunica tion” 76-0 Error SSIO communi cation (axis 1 - axis 2) configurable
18 E418 “Record seq. Unknown
cmd”
41-9 Error in path program jump destination configurable
19 E419 Rec ord seq. Invalid dest.” 41 -8 Path program error, unknown command configurable
20 “unknown” 64-1 DeviceNet general error PS off
64-2 DeviceNet communication error PS off
64-3 DeviceNet communication error PS off
64-4 DeviceNet communication error PS off
64-5 DeviceNet communication error PS off
64-6 DeviceNet communication error PS off
65-0 DeviceNet general error configurable
65-1 DeviceNet communication error configurable
23 E220 “PROFIBUS assembly” 22-0 Error in PROFIBUS initialisation PS off
