A Diagnostic messages
Festo – GDCP-CMMS/D-FW-EN – 1404NH – Engli sh 231
Diagnostic messages
Code ReactionMessageNo. bitNo.
7582h 64-0 52 DeviceNet communication error PS off
64-2 52 DeviceNet communication error PS of f
64-3 52 DeviceNet communication error PS of f
64-4 52 DeviceNet communicat ion error PS off
64-5 52 DeviceNet communication error PS of f
64-6 52 DeviceNet communication error PS of f
65-1 52 DeviceNet communication error Configurable
7584h 64-1 44 DeviceNet general error PS off
65-0 44 DeviceNet general error Configurable
76 80h 29-0 48 No SD Configurable
76 81h 29-1 49 SD initialization error Configurable
76 82h 29-2 50 SD parameter set e rror Configurable
8000h 45-0 21 Driver supply error PS off
45-1 21 Driver supply error PS off
45-2 21 Driver supply error PS off
05-2 21 Driver supply error/driver supply failed PS off
8087h 45-3 22 DIN4 plausibility error PS off
8100h 76-0 41 Error SSIO communication (axis 1 - axis 2 ) Configurable
76-1 40 Error S SIO communication (axis 2) Configurable
8130h 12-4 23 CAN: Time-out nodeguarding Configurable
8181h 12-0 54 CAN: Ge neral error Configurable
12-1 54 CAN: Error bus off Configurable
12-2 54 CAN: Error when transmitting Configurable
12-3 54 C AN: Error receiving Configurable
12-5 54 C AN: Error in the IPO mode Configurable
8600h 42-4 29 Message, homing required Configurable
8611h 17-0 28 Following error monitoring Configurable
8612h 40-0 31 Negative software limit switch reached Configurable
40-1 31 Positive software limit switc h reached Configurable
40-2 31 Target position lies behind the negative software limit
switch
Configurable
40-3 31 Target position lies behind the positive software limit
switch
Configurable
43-0 30 Negative limit switch error Configurable
43-1 30 Positive limit switch error Configurable
43-9 30 Limit switch error Configurable
86 81h 42-1 59 Positioning: Error in pre-computation Configurable
8A81h 11-1 35 Homing error PS off
