5 Commissioning
82 Festo – GDCP-CMMS/D-FW-EN – 1404NH – English
5.1.6 Fieldbu s address/MAC-ID configuration
The address/ID configuration is evaluated for each power ON procedure or controller reboot ( FCT). The
address/MAC-ID can be configured via the DIL switches [S1.1…7].
Fieldbus
DIL switch
[S1.7] [S1.6] [S1.5] [S1.4] [S1.3] [S1.2] [S 1.1]
Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
2
6
=64 2
5
=32 2
4
=16 2
3
=8 2
2
=4 2
1
=2 2
0
=1
CANOpen
CAN address: 1…127 X X X X X X X
DriveBus
CAN address: 2…13 – – – X X X X
PROFIBUS DP
Bus address: 3…126
1)
X X X X X X X
DeviceNet
MAC-ID: 0…63 – X X X X X X
RS485
Address: 0…127 X X X X X X X
Example: 57 =
(Switch position)
+0
(OFF)
+32
(ON)
+16
(ON)
+8
(ON)
+0
(OFF)
+0
(OFF)
+1
(ON)
1) The addresses “0…2” in Profibus DP are assigned to defined interfaces (e.g.: Higher-order controller, etc.).
Tab. 5.2 Fieldbus a ddress/MAC-ID configuration
Note the instructions f or address/MAC-ID parameterisation of fieldbuses
 Description “device profile FHPP”, GDCP-CMMS/D-C-HP-...
 Description “device profile CiA 402”, GDCP-CMMS/D-C-CO-...
