FIMER_PVS-175-TL A.1 Version_Product manual_EN_RevC-
F
50
It is required to use one of the following lifting methods to move the equipment during installation or
maintenance phases:
PVS-175
Kit of M8 handles (04) (to be ordered)
PVS-175
M8 Eyebolts UNI2947 (not supplied)
ATTENTION – A Always consider the center of gravity of the enclosures while lifting.
ATTENTION – A Always completely tight the thread of the handles or eye-bolt before lifting.
