PVS-175
Center of gravity (wiring box)
Center of gravity (power module)
ATTENTION – A In case of manual lifting it’s suggested to use a support plan (e.g. a table)
to place the equipment during the lifiting operation, in order to allow the change of hands
position.
A
B
A B
