Tables
Seite/Page 196 - Kaptitel/Chapter 9: Tables 18.12.15
² progressive speed by VCS
³ 0,35l/kW electrical power, the randomized values between 30% and 80% of
the rated speed
Fig. 9.1-3: Technical Data
Rated speed 3000 rpm 3000 rpm 3000 rpm 3000 rpm 3000 rpm
Idle running speed ² 3120 rpm 2900 rpm 3120 rpm 3100 rpm 2900 rpm
Valve clearance (engine cold) 0,2 mm 0,2 mm 0,2 mm 0,2 mm 0,2 mm
Cylinder head nut torque 42 Nm 42 Nm 42 Nm 42 Nm 42 Nm
Compression ratio 23:1 23:1 23:1 24:1 23:1
Lubrication oil capacity 2,8 l 2,8 l 3,8 l 2,8 l 3,8 l
Fuel consumption ³ approx. 0,5-1,4l approx. 0,7-1,8l approx. 0,8-2,1l approx. 1,0-2,66l approx. 1,1-2,8l
Oil consumption max. 1% of fuel consumption
Oil specification API CF API CF API CF API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
16-28l/min 16-28l/min 16-28l/min 16-28l/min 16-28l/min
Permissible max. permanent tilt of engine a) 25° across the longitudinal axis
b) 20° in the longitudinal direction
Recommend starter battery size 12V 28Ah
equivalent
12V 28Ah
equivalent
12V 36Ah
equivalent
12V 36Ah
equivalent
12V 36Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25mm² 25mm² 25mm² 25mm² 25mm²
Max. exhaust back pressure 9,3 kPa
93 Millibar
9,3 kPa
93 Millibar²
9,3 kPa
93 Millibar
9,3 kPa
93 Millibar
9,3 kPa
93 Millibar
Panda 6500
Panda 7 mini
Panda 8000
Panda 8 mini
Panda 9000 Panda 10000
Panda 9 mini
Panda 12000
Panda 12000 Panda 15000
15 mini digital
Panda 18 Panda 24 Panda 30
Type Mitsubishi MVL3E D902 D1105 V1505 V1505 TD
Governor xContol Servo VCS VCS VCS VCS
Automatic start booster yesyesyesno no
Cylinder 33344TD
Bore 76 mm 72 mm 78 mm 78 mm 78 mm
Stroke 70 mm 73,6 mm 78,4 mm 78,4 mm 78,4 mm
Stroke volume 952 cm³ 898 cm³ 1123 cm³ 1498 cm³ 1498 cm³
Max. power (DIN 6271-NB) at 3000rpm 17,5 kW 18,7 kW 23,3 kW 31,3 kW
Rated speed 3000 rpm 3000 rpm 3000 rpm 3000 rpm
Idle running speed ² 2900 rpm 2900 rpm 2900 rpm 2900 rpm
Valve clearance (engine cold) 0,2 mm 0,2 mm 0,2 mm 0,2 mm
Cylinder head nut torque 42 mm 68 Nm 68 Nm 68 Nm
Compression ratio 23:1 24:1 22:1 22:1 23:1
Lubrication oil capacity 3,6 l 3,7 l 5,1 l 6,0 l 6,7 l
Fuel consumption ³ approx. 1,1-2,8l approx. 1,3-3,6l approx. 1,7-4,5l approx. 2,2-5,9 approx. 2,7-7,2l
Oil consumption max. 1% of fuel consumption
Oil specification API CF-4 API CF API CF API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
16-28l/min 16-28l/min 28-40l/min 28-40l/min 40-50l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12V 36Ah
equivalent
12V 52Ah
equivalent
12V 65Ah
equivalent
12V 70Ah
equivalent
12V 70Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25mm² 25mm² 25mm² 25mm² 25mm²
