² progressive speed by VCS
³ 0,35l/kW electrical power, the randomized values between 30% and 80% of
the rated speed
Fig. 9.1-4: Technical data
² progressive speed by VCS
³ 0,35l/kW electrical power, the randomized values between 30% and 80% of
the rated speed
Fig. 9.1-5: Technical data
Max. exhaust back pressure 9,3 kPa
93 Millibar²
10,7 kPa
107 Millibar
10,7 kPa
107 Millibar
10,7 kPa
107 Millibar
Panda 12000 Panda 15000
15 mini digital
Panda 18 Panda 24 Panda 30
Panda 30 IC Panda 40 LN Panda 47 LN Panda 60 MB Panda 75 MB
Type Kubota V 1505 TB LDW 2204 MT LDW 2204T Mercedes Benz
OM602
Mercedes
OM603A
Governor VCS VCS VCS mechanical + VCS mechanical +
VCS
Automatic start booster yes no no no no
Cylinder 4445 6
Bore 78 mm 88 mm 88 mm 89 mm 89 mm
Stroke 78,4 mm 90,4 mm 90,4 mm 92,4 mm 92,4 mm
Stroke volume 1498 cm
3
2199 cm
3
2199 cm
3
2874 cm
3
3500 cm
3
Max. power (DIN 6271-NB) at 3000rpm 31,3 kW 36 kW 36 kW 69 kW 69 kW
Rated speed 3000 rpm 3000 rpm 3000 rpm 4000 rpm 3000 rpm
Idle running speed ² 2900 rpm 3000 rpm 3000 rpm 2900 rpm
Valve clearance (engine cold) 0,2 mm Hydro Hydro 0,2 mm
Cylinder head nut torque 63,7 - 68,6 Nm 68 Nm 68 Nm 25 Nm
Compression ratio 22,5:1 22:16 22:16 22:1
Lubrication oil capacity 6,0 l 6,4 l 6,4 l 7,5 l 7,5l
Fuel consumption ³ approx. 2,7 - 7,1l approx. 4,9-13,1l approx. 3,78-10,1l approx. 6,3 - 16,8 l approx. 6,7 - 17,9l
Oil consumption max. 1% of fuel consumption max. 0,5% of fuel consumption
Oil specification API CF API CF API CF-4 API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
40-50l/min 40-50l/min 40-50l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12V 70Ah
equivalent
12V 88 Ah
equivalent
12V 88 Ah
equivalent
12V 95 Ah
equivalent
12V 95 Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25mm² 50mm² 50mm“ 70mm² 70mm²
Max. exhaust back pressure 10,7 kPa
107 Millibar
10 kPa
100 Millibar
10kPa
100 Millibar
Panda 7,5-4 Panda 9-4 Panda 12-4 Panda 17-4 Panda 22-4
Type Kubota D905 Kubota D1105 Kubota V1505 Kubota V2203 Kubota V2403
Governor mechanical +
VCS
VCS VCS VCS VCS
Automatic start booster no no no no no
Cylinder 33444
Bore 72 mm 78 mm 78mm 87 87 mm
Stroke 73,6 mm 78,4 mm 78,4mm 92,4 102,4 mm
Stroke volume 898 ccm 1123 ccm 1498cm
3
2197 2434 ccm
Max. power (DIN 6271-NB) at 3000rpm 17,5 kW 18,7 kW 23,3kW 20,1 KW 31,1 kW
