Flexicon PF7 - View Batch Report

The report data stored and output by the PF7 are the values for the following:
Table 15 - Report data
l Software Version l Tube size
l Batch number - unique ID l Acceleration
l Start time and date l Deceleration
l User name l Anti-drip
l Batch name l Start delay
l Recipe name l End delay
l Volume l Between fill delay
l Density l Batch size
l Calibration values
l Whether calibration values fall
within the defined limits
l Speed
l Recipe setting changes while
dispensing
These report values will be shown if FDA 21CFR Part 11 compliance was enabled
when the report was created:
l Batch approval
l Date
l User
24.1 View batch report
Displays a list of batch reports saved on the pump. Ordered by the date and time
batch was completed.
Select from the list to view.
PF7/PF7+ Peristaltic Filler with QC14 Pumphead User Manual 101
