Flexicon PF7 - Advanced Operation and Specifications; Dispense Modes and Batch Management

23 Dispense mode
To start a batch on a PF7 refer to "Start manual batch" on the next page.
To start a batch on a PF7+:
• Refer to "Start manual batch" on the next page.
• Refer to "Start Zero waste batch" on page 91.
Figure 24 - Feature availability by pump and balance configuration
Configuration
Feature Pump
Calibration
in volume
Balance not
connected
to pump
Balance
connected to
pump
Filling on
balance
with
Advanced
filling kit
Start
manual
batch
PF7 Yes Yes Yes No
PF7+ Yes Yes Yes No
Start
zero
waste
batch
PF7+ No No
Not
recommended
Yes
23.1 Batch size
Enter the number of fills to be completed in the batch.
• Minimum - 1
• Maximum - 999999
23.2 Batch name
Name given to the batch. Maximum 12 characters.
PF7/PF7+ Peristaltic Filler with QC14 Pumphead User Manual 81
