8 Key features of QC14 pumphead
Figure 2 - Key features of QC14 pumphead
Table 2 - Key features of QC14 pumphead
Name Description
1. Tube Bridge The removable upper portion of the pumphead.
2.
Locking
lever*
Locks the tube bridge in place.
3. Track
Maintenance free spring loaded track fingers.
Accommodate different Accusil tube sizes
without adjustment.
4. Rotor Rotates to produce smooth accurate flow.
5. Access tray*
Removable tray for pumphead cleaning. (Note:
Access tray is consumable wearing part)
*Pumphead safety—Pump will only operate when the integral safety switches are
in the correct position.
PF7/PF7+ Peristaltic Filler with QC14 Pumphead User Manual 18
