159 PF7/PF7+ Peristaltic Filler with QC14 Pumphead User Manual
28 Pump specifications
Table 32 - Pump specifications
Specification Rating
Operating
environment
Indoor use only
Suitability
Dry biotechnology and pharmaceutical manufacturing
environments
Operating
temperature
5 °C to 40 °C (41 °F to 104 °F)
Storage temperature -40 °C to 70 °C (-40 °F to 158 °F)
Humidity (non-
condensing)
80% up to 31 °C (88 °F) decreasing linearly to 50% at
40 °C (104 °F)
Maximum altitude 2000 m (6560 ft)
Supply voltage 100-120 V/200-240 V 50/60 Hz 1 pH
Maximum voltage
fluctuation
+/-10% of nominal voltage.
Power consumption 140 VA
Full load current <0.6 A@ 230 V; <1.25 A @ 115 V
Fuse rating Ceramic, 5x20 mm, 2.5 A, 250 VAC, Time Delay
Installation category
(overvoltage
category)
II
Pollution degree 2
Protection class IP32 to BS EN 60529
Sound level <70 dB (A) @ 1 m
Control ratio PF7 30-400 rpm (370:1), PF7+ 30-600 rpm (570:1)
Maximum speed PF7 400 rpm, PF7+ 600 rpm
Weight PF7 12.5 kg (27 lb 10 oz), PF7+ 10.9kg (24 lb)
USB (PF7+) 4 x Type A USB 2.0 High Speed 500 mA
