Flexicon PF7 - Lifting and Carrying

17 PF7/PF7+ Peristaltic Filler with QC14 Pumphead User Manual
7 Lifting and carrying
Disconnect the power cable and other wired connections and
remove the tube from the pumphead before moving the pump.
Failure to do so could result in a trip hazard or damage to the
pump, cables, connectors or tube.
Lift the pump according to standard Health and Safety guidelines
using both lifting points. (Refer to "Lifting point locations" below)
DO NOT lift the pump by holding the pumphead as the access tray
can disengage.
1
1
1 Lifting points
Figure 1 - Lifting point locations
