72 PF7/PF7+ Peristaltic Filler with QC14 Pumphead User Manual
Calibration outside an acceptable level
If the calibration value entered is outside of ±95% of the target value:
• A warning screen is displayed.
• Calibration cannot continue.
• Check the value was entered correctly.
• Check the tube size is as per the recipe.
• Check the fluid path is set up correctly.
Calibration with fill tolerance limits
Refer to "Fill tolerance" on page 63 to enable fill tolerance limits.
22.1.2 Calibration summary
A calibration summary will be displayed. If the values are correct, press to
complete the calibration process.
The following are added to the report, for each calibration since the last recipe
change or since the pump was powered on:
• Data/time of calibration
• Calibration volume
• Active username when calibration was done
