144 PF7/PF7+ Peristaltic Filler with QC14 Pumphead User Manual
27.2.1 User Interface
1 2 3 4 6
8
97
5
Figure 52 - NetTools User Interface
1 Refresh button—Refreshes the information in the pumps panel.
2
Pumps panel—Displays a list of connected pumps and the data stored
on that pump.
3
Save as PDF—Saves the selected report or audit as a PDF file on your
PC.
4 Tabs—Files that are open, but not selected.
