27 PF7/PF7+ Peristaltic Filler with QC14 Pumphead User Manual
i
Fitting tube with tube
lock
(optional - twin infeed)
(Note: Tube locks are
consumable wearing
parts)
If using a twin infeed, secure the tube with the correctly sized tube
lock. Pumping performance can be affected.
Figure 9 - Loading the tube into the pumphead
